Digitrack 18
Digital Mixing Console

Digitrack 18
Key Features
8 models with 2 and 4 channel versions
XLR balance XLR inputs
example 1
example 2 ….. e.t.c
Overview
The HX series are our ultra lightweight, compact yet packed with high performance power ratings and features and available in eight models. All models feature comprehensive protection and status indicators, and are in 2 and 4 channel variants offering from 2 x 225 watts at 4ohms up to 4 x 765 watts. The HX series are all 1U size, with power factor correction (PFC), universal power supplies with will operate between 90-250VAC, and will perform at loads down to 2ohms. For demanding installation, conference, entertainment and smaller touring and rental applications, the new HX series will supply the performance, power and reliability you need in a compact, affordable package.
Example
Specification
MIC/LINE Input | 16 channels 12 x XLR/4 x COMBO XLR/JACK | |
Master Output | 2 Left/Right balanced XLR | |
Smart Outputs | 6 assignable balanced XLR | |
Internal busses | 16 | |
DCA groups | 6 DCA groups | |
Stereo Monitor | 2 XLR output | |
Headphone | 1 TRS Jack output | |
Screen | 7" high definition touch screen | |
Faders | 8 x motorized 100 mm faders + 1 x motorized 100mm fader for L/R mix | |
Layers | multiple channel/bus layers + 2 custom user layers | |
Sample Frequency | 48kHz | |
AD/DA | 192kHz, 24-bit | |
DSP | 40-bit float point, SHARC processor | |
Remote control | Cross platform - Any device with Wi-Fi / Lan and web browser | |
Effects | up to 8 assignable effect modules (reverb, modulation, delay, 31 band GEQ with RTA) | |
AES/EBU | Output (XLR) | |
S/PDIF | Input / Output (RCA phono) | |
USB Interface | 2 USB type A for playback/recording, scene storage and system updates | |
option - 1 USB type B for 16 x 16 USB audio connection to PC/computer DAW | ||
2 RJ45 sockets for digital audio in/out to LAN | ||
Network | yes via WIFI external module | |
Power | 90-240V ~ 50/60Hz power supply 24VDC output | |
Dimension (W x H x D) | 585 x 465 x 230mm | |
Net Weight | 7.5kg |
