V6SA
Line Array System

V6SA
Key Features
High performance 1 x 15″ LF driver with 4″ / 100mm voice coil
High performance 130dB SPL
Convenient scoop handles
Adjustable suspension system available
Overview
Active line array systems tend to be heavy, bulky and prone to
damage if used in rentals or live touring conditions.
The V6 6.5″ MF/HF cabinet is made from durable but hard wearing
reinforced PP composite material giving it superior weight
advantages.
Built in high performance power amplifier, DSP control and
powerful twin 6.5″ drivers with 38mm voice coils. The 3″
neodymium HF driver has a 74mm voice coil, giving the V6A
MF/HF enclosure up to 130dB SPL

The V6SA LF unit designed to work with the V6A features a single
high performance 15″ driver with a large 4″ / 100mm voice coil
capable of handling the 1200W power amplifier built in to the
enclosure.
Like the V6A, the LF unit includes built in DSP to make tuning and
setting up your system as easy as possible.

Specification
V6SA
MAX SPL¹ | 130dB |
AMP POWER² | 1200W |
WEIGHT | 41kg |
Cabinet type | active line array woofer |
Frequency response | 40Hz - 150Hz (-10dB) |
Coverage (H × V) | - |
Sensitivity (1W@1m) | 0dBu |
Impedance | - |
LF Driver | 1 × 15" / 100mm VC |
MF Driver | - |
HF Driver | - |
DSP | gain, EQ, crossover, delay, threshold |
Crossover frequency | DSP controlled |
Vertical splay angle | - |
Dimensions (W × H × D) | 474 × 506 × 673mm |
