V10SA
Line Array System

V10SA
Key Features
2 x 15″ LF drivers using vented horn design to improve efficiency Large 4″ voice coils to deliver
consistent high power
Durable finish
Adjustable suspension system and convenient
Overview
Compact design with a high performance versus cost ratio,
high SPL, superb intelligibility, low distortion and a flexible
configuration.
Two-way linear sound dispersion technique to provide clear
rich sounds.
Low/medium frequency driver with ultra low distortion to give
high performance with a wide dynamic range.
Custom high quality titanium and neodymium HF compression
driver.
Super Hi-Fi sound from the flat phase response.
Birch plywood cabinet coupled with CNC routed slotted
structure to give a great sound and extreme strength and
rigidity.
Hard wearing water based surface treatment, to give a long
lasting weatherproof finish.
Intelligent fast fixing suspension system.

Gallery
Specification
V10SA
MAX SPL¹ | 132dB |
POWER² | 1500W |
WEIGHT | 44kg |
Cabinet type | active line array woofer |
Frequency response | 32Hz - 400Hz (-10dB) / 35Hz - 300Hz (+/-3dB) |
Input sensitivity | 0dBu |
Coverage (H × V) | - |
MF/LF Driver | 1 × 18" |
HF Driver | - |
Vertical spread angle | - |
Dimensions (W × H × D) | 810 × 560 × 820mm |
