mixBRIDGE6
UNIQUE HYBRID AUDIO INTERFACE AND MIXING CONSOLE

mixBRIDGE6
Key Features
6 inputs (2mic/2stereo) with 2 track (stereo) USB recording
TRRS AUXinput with me-minus, control live calls in podcasts or livestreams
Multiole inout choes-2x Stereo inputs
Professional MIC/LINE level inputs
Overview
The mixer is compact and lightweight, with external DC12V power supply, 2-4 CH mic inputs and 2 CH stereo inputs. Among them, the
microphone 1/2 channel adds high impedance input function. lt is convenient for guitar playing, built-in professional USB interface, which can connect computer playback and recording, and the mixer also has a live broadcast function. lt can connect mobile phone live, tiktok, etc., and has comprehensive professional characteristics. No matter solo, recording or performance can satisfy the application requirements.

Specification
mixBRIDGE6
USB Output | 2 track (L-R) |
USB Input | 2 track |
USB Sampling rate | 24bit/48kHz |
MIDI Interface | n/a |
MIC/LINE Inputs | 2 x COMBO (2 x mic / 1 x line / 1 x hi-z) |
Phantom Power | +48V all mics individually switched |
Stereo Inputs | 4 x 1/4" (6.35mm) jacks |
Channel EQ | 2 band HI / LO |
AUX/PHONE Input | 1 x 1/8" (3.5mm) TRRS (mix-minus) jack |
MIX Output | 2 x 1/4" (6.35mm) balanced jacks |
AUX/MONITOR Output | 1 x 1/4" (6.35mm) mono jack |
MIC Gain | +6dB to +50dB |
LINE Gain | +10dB to -34dB |
MIC EIN | <-100dB |
Frequency response | 10Hz - 20kHz +1/-3dB |
THD | <=0.03% |
S/N Ratio | 80dB |
Output Level | MAX +20dB (unbal/balanced) |
EQ HI Frequency | 12kHz (+/- 15dB) |
EQ LO Frequency | 80Hz (+/- 15dB |
Power Supply | 12V DC external PSU |
Dimensions (W x H x D) | 253 x 55 x 210mm |
Net Weight | 2.1kg |
