CLUB XS5+
Compact Mixing Console

CLUB XS5+
Key Features
6 MODELS 5/6/8/10/12/16 input versions available
BLUETOOTH playback facility
USB/SD CARD media playback module
DSP reverb effect
Overview
The Studiomaster CLUBXS+ series are a range of comprehensive and affordable compact, hard wearing mixing consoles. With all the features required for live mixing or stereo recording an event, duo or band whether at home, in the rehearsal rooms or out at an event.
The compact range is available in 5 to 12 input versions.

Specification
Inputs | 5 | |
Mic Input channels | 1 | |
Stereo Input channels | 2 | |
Gain | MIN ~ MAX | |
Mic | 6dB ~ +50dB | |
Line | +10dB ~ -34dB | |
EIN | -100dB | |
Frequency response | ||
Mic Channel | 10Hz~20kHz+1/-3 | |
THD Mic Channel |  0.1% | |
Signal to noise ratio | 80dB | |
Output Levels | MAX +26(BAL) / MAX +20(UNBAL) | |
Channel EQ | ||
Hi | 12kHz | |
Mid | 2.5kHz | |
Lo | 45Hz | |
Lo Cut | 80Hz | |
MP3/USB/SD Audio playback | YES | |
USB/SD Audio recording | YES | |
DSP Effects | YES | |
Power requirements | 100V - 240V ~ | |
Dimension (W x H x D) mm | 195 x 80 x 270 | |
Weight | 3kg |
