CLUB XS10+
Compact Mixing Console

CLUB XS10+
Key Features
6 MODELS 5/6/8/10/12/16 input versions available
BLUETOOTH playback facility
USB/SD CARD media playback module
DSP EFFECTS 16 quality reverb, delay and stereo effects
Overview
The Studiomaster CLUBXS+ series are a range of comprehensive and affordable compact, hard wearing mixing consoles. With all the features required for live mixing or stereo recording an event, duo or band whether at home, in the rehearsal rooms or out at an event.
The compact range is available in 6 to 16 input versions with 19” rack adapters or dedicated 19” rack mounting models to fulful virtually any
application.

Specification
Inputs | 10 | |
Mic Input channels | 6 | |
Stereo Input channels | 2 | |
Gain | MIN ~ MAX | |
Mic | 6dB ~ +50dB | |
Line | +10dB ~ -34dB | |
EIN | -100dB | |
Frequency response | ||
Mic Channel | 10Hz~20kHz+1/-3 | |
THD Mic Channel | 0.1% | |
Signal to noise ratio | 80dB | |
Output Levels | MAX +26(BAL) / MAX +20(UNBAL) | |
Channel EQ | ||
Hi | 12kHz | |
Mid | 2.5kHz | |
Lo | 45Hz | |
Lo Cut | 80Hz | |
MP3/USB/SD Audio playback | YES | |
USB/SD Audio recording | YES | |
DSP Effects | YES | |
Power requirements | 100V - 240V ~ | |
Dimension (W x H x D) mm | 360 x 80 x 365mm | |
Weight | 5kg |
