Direct 101
Column Speaker

Direct 101
Key Features
Self-powered 3-way system for high definition sound
120° x 30° ultra wide sound coverage (H x V)
Extensive 4-channel mixer
6 × 3″ + 1 × 1” full-range column speaker, 10″ bass reflec sbu
Overview
The self-powered all-in-one solution is an ultra-compact, powerful vertical array system for versatile use. DIRECT includes 6 x 3″ mid frequency transducers for perfect clarity of instruments and sound. The 1″ high precision driver delivers dynamic and clear highs.
The subwoofer is featured by one professional 10″ or 12″ transducer for well-defined lows.
The on-board 4-channel mixer enables for a wide range of applications. Connecting microphones, instruments, players or even wireless bluetooth streaming sources: DIRECT is ready for it. The built-in DSP with it’s graphic display upgrades your sound to high definition audio quality.

Specification
DIRECT101
Inputchannel | 4-channel(2xMic/Line,1xRCA,1xHi-Z) |
Input connector | 1-2# : XLR/6.3mm jack combo |
3#: 6.3mm jack balanced TRS | |
4#:2xRCA | |
Input impedance | 1-2# MIC: 40 k Ohms balanced |
Input impedance | |
1-2# LINE:10 k Ohms balanced | |
3# : 20 k Ohms balanced | |
4#:5kOhms unbalanced | |
Output connector | 1-2#: Line Link :XLR 3#:Mix out :XLR |
Speaker | 1x10"woofer |
Rated power | 250W(RMS) |
Rated impedance | 4Q |
Box size (width × height x depth) | 374 x616x 465mm |
Sound box net weight(kg) | 21.2kg |
Ratedpower | 2×300WRMS |
Frequency range | 20Hz--20kHz |
DSPconnection | 24bit(1-in-2-out) |
